Knightsbridge Driver, LED Constant Voltage IP20
SKU:
24DC200M
Brand:
Knightsbridge
Available to Order
Key Features
✓ Ingress protection rated IP20
✓ Energy efficient 200 W consump...
✓ 3 Years manufacturer warranty
📝 Product Description
24V IP20 200W DC Driver - Constant Voltage
📋 Detailed Information
Driver, LED Constant Voltage IP20
A quality product from Knightsbridge in the LED Drivers/Controllers category, designed for professional electrical applications.
Available for immediate dispatch from WRM Electrical.
All electrical products should be installed by qualified personnel in accordance with current regulations.
⚡ Key Features
- ✓ Ingress protection rated IP20
- ✓ Energy efficient 200 W consumption
- ✓ 3 Years manufacturer warranty
📋 Technical Specifications
Technical Document 5
https://www.luckinslive.com/data/4b97aa58-21e5-45b0-9a06-5a40276bec34/3cf4db78-c3bd-4d80-81eb-c8c0caeb8026.PDF
Category
LED Drivers/Controllers
Product
Driver
Type
Constant Voltage
Primary Voltage
110|230 V
Secondary Voltage
24 V
Secondary Voltage Type
DC
Secondary Current
0|8.8 A
Dimmable
N
Wattage
200 W
Ingress Protection
IP20
Material
Aluminium
Colour
Silver
Length
215 mm
Width
115 mm
Depth
30 mm
Maximum Operating Temperature
50 Degrees C
CE Approved
Y
UKCA Approved
Y
Warranty
3 Years
Dimensions
200W 24V DC
Finish
Stainless Steel
Unit Weight
0.6 kg
📚 Technical Documents & Datasheets
📄
Catalogue Page
dd243700-27b9-4b59-a4ea-da5e990635f7.PDF
Click to download
📄
Installation Instructions
6e7c8bcd-3e08-4fce-a5ad-858ab5e4aa6c.PDF
Click to download
📄
Technical Data Sheet
aec471cf-18b6-41eb-939d-dd45cf049606.PDF
Click to download
📄
Certifications
5aa023e5-a376-4f8e-bf8f-037adfa6c0f5.PDF
Click to download
📄
Certifications
3cf4db78-c3bd-4d80-81eb-c8c0caeb8026.PDF
Click to download
