Lewden Ltd RCBO, B Curve 1 Module Type A
SKU:
RCBO10-45/30/1MBA
Brand:
Lewden
Available to Order
📦 Typically 3-4 days delivery
Key Features
✓ Ingress protection rated IP20
Pricing
Special price applied
£35.11
£42.13 Inc VAT
My Scraps
Stock Availability
i
Pickup ordering is available at checkout via Click &
Collect.
📞 Please contact us for current stock availability
Stock levels are updated regularly
📝 Product Description
LEWDEN RCBO 45A 30mA B Curve 1mod 10kA Type A
📋 Detailed Information
LEWDEN RCBO 45A 30mA B Curve 1mod 10kA Type A
All electrical products should be installed by qualified personnel in accordance with current regulations.
⚡ Key Features
- ✓ Ingress protection rated IP20
📋 Technical Specifications
Category
RCBO
SKU
RCBO10-45/30/1MBA
Product
RCBO
Type
Current
Pole Configuration
SP+N
Number of Modules
1
Voltage Type
AC
Ingress Protection
IP20
Trip Type
Type B
Short Circuit Rating
10 kA
Sensitivity
30 mA
Cable Capacity
25 mm2
Height
126 mm
Width
18 mm
Depth
76 mm
Operating Temperature Range
-25|40 Degrees C
RCD Type/Class
A
Current Rating
45 A
Voltage
230-240 V
Frequency
50/60 Hz
CE Approved
N
Standards
EN 61009-1
Dimensions
45A 30mA 10kA
Unit Weight
0.164 kg
