BG Electrical Accessories Ltd Downlight, Platinum c/w Dim 250mA Driver IP44, Tridonic
SKU:
LDP20W12GD40-15
Brand:
BG Electrical Accessories
Available to Order
📦 Typically 3-4 days delivery
Key Features
✓ Dimmable for adjustable lighti...
✓ Ingress protection rated IP44
✓ Energy efficient 9.5 W consump...
✓ 90 Degrees beam angle for opti...
Pricing
Special price applied
£129.89
£155.87 Inc VAT
My Scraps
Stock Availability
i
Pickup ordering is available at checkout via Click &
Collect.
📞 Please contact us for current stock availability
Stock levels are updated regularly
📝 Product Description
PLATINUM D-LIGHT 218MM 1250LM 9.5W 4000K DIGITAL D
📋 Detailed Information
PLATINUM D-LIGHT 218MM 1250LM 9.5W 4000K DIGITAL D
All electrical products should be installed by qualified personnel in accordance with current regulations.
⚡ Key Features
- ✓ Dimmable for adjustable lighting control
- ✓ Ingress protection rated IP44
- ✓ Energy efficient 9.5 W consumption
- ✓ 90 Degrees beam angle for optimal light distribution
- ✓ 4000 K colour temperature
- ✓ 5 Years manufacturer warranty
- ✓ Recessed mounting for clean ceiling appearance
- ✓ Die Cast Aluminium construction with Gloss/White finish
📋 Technical Specifications
Technical Document 5
https://www.luckinslive.com/data/d97b4c8f-9a60-4103-9614-cc7fe5248a2d/0cfca575-354c-45c3-8bcf-9e4ecde98e52.PDF
Technical Document 6
https://www.luckinslive.com/data/d97b4c8f-9a60-4103-9614-cc7fe5248a2d/c3217032-35b1-435a-a08a-c1bbb3f644fc.PDF
Category
Downlights
SKU
LDP20W12GD40-15
Product
Luminaire
Type
Downlight
Lamp Type
LED Fixed
Face Shape
Circular
Mounting Position
Ceiling
Mounting Type
Recessed
Adjustability
Fixed
Fire Rated
N
Dimmable
Y
Cover Included
Y
Cover Type
Reflector
LED Driver Included?
Y
Wattage
9.5 W
Ingress Protection
IP44
Emergency
N
Housing Material
Die Cast Aluminium
Bezel/Trim Colour
White
Cover Material
Aluminium
Cover Colour
Gloss
Overall Diameter
223 mm
Cut Out Diameter
205 mm
Depth
116 mm
Beam Angle
90 Degrees
Colour Temperature
4000 K
Light Output
1200 Lm
Colour Rendering Index
>80
Voltage
220-240 V
Luminous Efficiency
126 Lm/W
CE Approved
Y
Standards
EN 60598-1 EN 60598-2-2 EN 60598-2-22 EN 61347-1 EN 61347-2-13 EN 55015 EN 61547 EN 61000-3-2 EN 62471 2002/96/EC 2011/65/EU (EC) No 1907/2006
Warranty
5 Years
Dimensions
1200lm
Finish
Gloss/White
Unit Weight
1.1 kg
📚 Technical Documents & Datasheets
📄
Catalogue Page
e13062fd-e99b-402d-add1-f9312baef389.PDF
Click to download
📄
Overview
4168fffc-fcc6-42f4-ad56-126d5a1c8c05.PDF
Click to download
📄
Overview
fda7c6f6-f6c5-41fe-aefc-5731871ccc14.PDF
Click to download
📄
Installation Instructions
500a9c64-dec6-4503-b4ec-527dcae98d12.PDF
Click to download
📄
Technical Data Sheet
0cfca575-354c-45c3-8bcf-9e4ecde98e52.PDF
Click to download
📄
Certifications
c3217032-35b1-435a-a08a-c1bbb3f644fc.PDF
Click to download
