CLICK ELUCIAN 1 Pole True 6kA B Curve 32A MCB Light Grey (RAL 9035)
SKU:
CU1MCB32B
Brand:
CLICK
Available to Order
Single Pole True 6kA. B Curve with thermal / magnetic trip release, large terminal capacity & lockable switch (with compatible kit)
Key Features
✓ Single Pole
✓ True 6kA
✓ B Curve
✓ Thermal / Magnetic Trip Releas...
📝 Product Description
1 Pole True 6Ka B Curve 32A MCB
📋 Detailed Information
Single Pole True 6kA. B Curve with thermal / magnetic trip release, large terminal capacity & lockable switch (with compatible kit)
⚡ Key Features
- ✓ Single Pole
- ✓ True 6kA
- ✓ B Curve
- ✓ Thermal / Magnetic Trip Release
- ✓ Large Terminal Capacity
- ✓ Lockable switch (with compatible kit)
ℹ️ Product Information
🏭
Brand
CLICK
📋 Technical Specifications
Brand
CLICK
Family
Elucian
Range
MCB Devices - B Curve
Flush mounted installation
Rated impulse withstand voltage (Uimp)
4
Rated short circuit breaking capacity Icu IEC 60947 2 at 400 V
6
Rated short circuit breaking capacity Icu IEC 60947 2 at 230 V
6
Rated short circuit breaking capacity Icn EN 60898 at 230 V
6
Rated short circuit breaking capacity Icn EN 60898 at 400 V
6
Number of poles (total)
1
Additional equipment possible
Voltage type
AC
Ambient temperature during operating
-5
Connectable conductor cross section multi wired
1
Connectable conductor cross section solid core
2.5
Concurrently switching N neutral
Number of protected poles
1
Degree of protection (IP rating)
IP20
Explosion proof
Width in number of modular spacings
1
Rated insulation voltage Ui
500
Tripping characteristic (type/curve)
B
Frequency
50
Rated voltage
230
Rated current
32
Recess depth
70
